Zennio HeatingBOX 230V 4X Heating actuator ZCL-4HT230
Actuator for climate systems based on water pipes which allows the control of up to 4 outputs for on/off valves operated at 230 VAC by means of triacs with short-circuit protection. It includes one independent thermostat for each output and a module with 10 logical functions. It allows manual control of the outputs with status indication through LEDs.159.00 €
Frame sold separately
Buttons covers sold separately
-Large Rocker - Compatible with 2-button and 8-button module.
-2gang Median Rocker - Compatible with 4-button and 8-button module.
-1gang Median Rocker-2gang Small Rocker - Compatible with 6-button and 8-button module.
-4gang small Rocker - Compatible with 8-button module.
- The KNX dynamic display pushbutton can be equipped with 2 to 8 buttons on which different functions can be set.
- The functions and the associated labelling (text and symbol) are configured in ETS (5 or 6) or eConfigure KNX and displayed accordingly on the screen.
displayed accordingly on the screen.159.00 €
Schneider Power supply KNX -1280 mA - MTN6513-1201
SpaceLogic KNX Power Supply 1280 mA The SpaceLogic KNX power supply generates the bus voltage for the KNX line The power supply has two outputs – one KNX output with integrated choke and one DC 30 V output for additional devices The power supply has a floating signalling contact for operation and diagnostic message344.00 €
Schneider - KNX secure IP Interface - MTN6502-0105
This device from the Spacelogic KNX range is an IP Interface DIN Rail. The Spacelogic KNX IP Interface is an interface between IP and KNX. You can access the KNX Bus from every point of your LAN. The Spacelogic KNX IP Interface can be used as a programming interface for ETS 5 Software and allows to access the KNX bus over the Internet via a VPN. The device supports KNX Security which can be enabled in ETS. With its interface functionality (tunneling) KNX security prevents unauthorized access. The device supports up to 8 tunneling channels. For each tunneling channel, a separate individual address must be configured. The device is delivered with 2 integrated push-buttons to select the tunneling channel and 3 status LEDs. The Interface is powered by the KNX bus. An additional power supply is not needed. It allows mounting on DIN rails TH35 according to EN 60715. The bus is connected using a bus connecting terminal. This application requires ETS 5 or higher. The LAN network is connected via the RJ45 socket. The width of the device for 1 module is about 18mm. The device is delivered with bus connecting terminal and cable cover.228.00 €
Schneider - KNX secure USB Interface - MTN6502-0101
Spacelogic KNX USB Interface DIN Rail. For connecting a programming or diagnostics device with a USB 2.0 interface to the KNX. The USB connector (Type C) is galvanic isolated from the KNX bus. It can be used as a programming interface for ETS Software Version 4 (or higher). The device is programmed locally with the physical address and does not have a programming button and programming LED. With 2 status LEDs. The KNX USB interface supports KNX “longframe” communication and is compatible with KNX security telegrams/devices. This allows faster KNX downloads if supported by the target device (e.g. MTN6725-0001). For installation on DIN rails TH35 according to EN 60715. The bus is connected using a bus connecting terminal. Device width - 1 module = approx. 18 mm. Contents - With bus connecting terminal and cable cover.170.00 €
