Multifunction and shutter actuators


  • Interra combo actuator 16 outputs ITR516-16A

    Interra Combo ITR516-16A

    • Lighting control can be made with every output of the combo switch actuator.
    • Heating control can be made with every output of the combo switch actuator.
    • Every output of the combo module can be configured as shutter/blind provided that 2 consecutive outputs are available.
    • Shutter/blind 24V configuration can be with 4 outputs of the combo module. However, it is only available in the first four outputs of the (*) blocks.
    • Fan Coil 2 pipes configuration can be with 4 outputs of the combo module. However, it is only available in the first four outputs of the (*) blocks.
    • Fan Coil 4 pipes configuration can be with 5 outputs of the combo module. However, it is only available in the first five outputs of the (*) blocks.
    • The functionalities for each output include among other things timing functions, logic gates, scenes, disabling function, forced, working hours counter, periodical monitoring and different configurations for feedback telegrams.
    • Last situation memory against power failure.
    (*): Each block consists of every 6 outputs of the combo module that is starts from C1 output.

    365.00 €
  • Interra combo actuator 8 outputs ITR508-16A

    Interra Combo ITR508-16A

    • Lighting control can be made with every output of the combo switch actuator.
    • Heating control can be made with every output of the combo switch actuator.
    • Every output of the combo module can be configured as shutter/blind provided that 2 consecutive outputs are available.
    • Shutter/blind 24V configuration can be with 4 outputs of the combo module. However, it is only available in the first four outputs of the (*) blocks.
    • Fan Coil 2 pipes configuration can be with 4 outputs of the combo module. However, it is only available in the first four outputs of the (*) blocks.
    • Fan Coil 4 pipes configuration can be with 5 outputs of the combo module. However, it is only available in the first five outputs of the (*) blocks.
    • The functionalities for each output include among other things timing functions, logic gates, scenes, disabling function, forced, working hours counter, periodical monitoring and different configurations for feedback telegrams.
    • Last situation memory against power failure.
    (*): Each block consists of every 6 outputs of the combo module that is starts from C1 output.

    260.00 €
  • JUNG 8 On/Off outputs / 4 rolling shutter outputs KNX actuator 2308.16REGHE

    On/Off actuator: max. 8 On/Off contacts
    Blind and shutter actuator: max. 4 channels

    Controls up to 4 shutters or 8 lights

    Mixed actuator: max. e.g. 3-channel digital actuator / 1-channel blind/shutter actuator with electronic manual override and LED status display.

    Product family ETS: Outputs
    Type of product : Mixed binary output

    Appropriate use:

    • Switching of electrical consumers AC 230 V with potential-free contacts
    • Switching of electrically driven blinds, shutters, awnings and other suspensions
    • Rail mounting in small product dispensers

    Product characteristics:

    • Manually controllable outputs, construction site mode
    • Return to manual and bus operation
    • Scene function
    • Locking of individual outputs manually or by bus

    Switch mode characteristics:

    • Normally open contact mode or normally closed contact mode
    • Linking function and forced guide stop function
    • Return function
    • Central switching function with common feedback
    • Timer functions: switch-on delay, switch-off delay, staircase light switch and warning function

    Characteristics of the awning mode:

    • Suitable for 230 V AC motors
    • Directly controllable suspension position
    • Directly controllable slat position
    • Indication of the state of movement, the position of the curtain and the position of the slats
    • Position forced by the higher level control

    Safety function:

    • 3 independent wind, rain and frost alarms
    • Sunshade function

    You will find the technical documentation in the documents for this product.

    303.60 €
  • JUNG KNX switch actuator 16-gang KNX blinds actuator 8-gang 230161SR

    Jung 230161SR

    Rail mounting device, 8 rail units
    with manual electronic operation and LED status indication
    Project design and commissioning with ETS5 or a more recent version.
    ETS product family: Output
    Product type: Binary output

    Intended use

    • Switching of electrical loads with floating contacts
    • Switching of electrically-driven blinds, shutters, awnings and similar hangings
    • Mounting on DIN rail according to EN 60715 in distribution boxes


    Product characteristics

    • Outputs can be operated manually, construction site mode
    • Feedback in manual mode and in bus mode
    • Disabling of individual outputs manually or via bus
    • Central functions
    • Cyclical monitoring
    • Can be updated with the ETS Service App


    Characteristics switching operation

    • Operation as NO or NC contacts
    • Feedback function
    • Logic operation and forcing function
    • Central switching function with collective feedback
    • Time functions: switch-on delay, switch-off delay, staircase lighting timer with pre-warning function
    • Scene function
    • Operating hours counter


    Characteristics blinds operation

    • Suitable for 230 V AC motors
    • Operation modes ‘Blind with slats’, ‘Shutter/awning’, ‘Ventilation flap/skylight’
    • Blind/shutter position directly controllable
    • Slat position directly controllable
    • Feedback of movement status, blind/shutter position and slat position
    • Cyclical feedback during movement
    • Forced position through higher-level controller
    • Safety function: rain alarm, frost alarm, 3 independent wind alarms
    • Sun protection function with auto Heating/Cooling
    • Scene function


    The total current of two adjacent outputs must not exceed 20 A.

    280.00 €
  • MAXinBOX 16 V3 Zennio Actuator 16 outputs KNX

    MAXinBOX16 Multifunction Actuator 16 outputs 16A

    Characteristics:

    • Mounting on DIN rail (EN 50022), pressurized.
    • Does not require a power supply other than the bus power supply.
    • Integrated BCU KNX bus coupling unit
    • Equipped with 8 action channels configurable as:
      • shutter channels (up to 8)
      • individual outputs (up to 16)
    • Independent manual control by output with push button and LED status indicator.
    • Includes logic functions
    • Delay on outputs
    • Full data backup in case of power loss
    • Withstands capacitive loads, maximum 140 µF.
    • Complies with EC directives.

    SAFETY INSTRUCTIONS

    • Do not connect the main voltage (230V) or other external voltages to the KNX data bus.
    • Connecting an external voltage can endanger the electrical safety of the entire KNX system.
    • Use rigid cable to connect the outputs or flexible cable with terminals (spikes).
    • Always check during installation that there is sufficient insulation between the 230V main voltage conductors and the conductors of the Bus and its extensions.
    • It is possible to connect several phases, making sure that each phase is on a different terminal block (block 1, block 2, block 3 and block 4).
    • Once the device has been installed, the output terminals must not be accessible.

    429.00 €
  • MAXinBOX 66 V2 Zennio Actuator 6 outputs 6 inputs KNX - ZIOMB66V2

    MAXinBOX66 6 outputs 6 inputs KNX actuator

    Characteristics:

    • Mounting on DIN rail (EN 50022), pressurized.
    • Does not require a power supply other than the bus power supply.
    • Integrated BCU KNX bus coupling unit
    • Equipped with 6 action channels configurable as:
      • shutter channels (up to 3)
      • individual outputs (up to 6)
    • 6 analog/digital inputs.
    • Independent manual control by output with push button and LED status indicator.
    • Includes logic functions
    • Delay on outputs
    • Full data backup in case of power loss
    • Withstands capacitive loads, maximum 140 µF.
    • Complies with EC directives.

    SAFETY INSTRUCTIONS

    • Do not connect the main voltage (230V) or other external voltages to the KNX data bus.
    • Connecting an external voltage can endanger the electrical safety of the entire KNX system.
    • Use rigid cable to connect the outputs or flexible cable with terminals (spikes).
    • Always check during installation that there is sufficient insulation between the 230V main voltage conductors and the conductors of the Bus and its extensions.
    • It is possible to connect several phases, making sure that each phase is on a different terminal block (block 1, block 2, block 3 and block 4).
    • Once the device has been installed, the output terminals must not be accessible.

    271.00 €
  • MAXinBOX 8 V3 Zennio Actuator 8 outputs KNX

    MAXinBOX8 Multifunction Actuator 8 outputs 16A

    Characteristics:

    • Mounting on DIN rail (EN 50022), pressurized.
    • Does not require a power supply other than the bus power supply.
    • Integrated BCU KNX bus coupling unit
    • Equipped with 8 action channels configurable as:
      • shutter channels (up to 4)
      • individual outputs (up to 8)
    • Independent manual control by output with push button and LED status indicator.
    • Includes logic functions
    • Delay on outputs
    • Full data backup in case of power loss
    • Withstands capacitive loads, maximum 140 µF.
    • Complies with EC directives.

    SAFETY INSTRUCTIONS

    • Do not connect the main voltage (230V) or other external voltages to the KNX data bus.
    • Connecting an external voltage can endanger the electrical safety of the entire KNX system.
    • Use rigid cable to connect the outputs or flexible cable with terminals (spikes).
    • Always check during installation that there is sufficient insulation between the 230V main voltage conductors and the conductors of the Bus and its extensions.
    • It is possible to connect several phases, making sure that each phase is on a different terminal block (block 1, block 2, block 3 and block 4).
    • Once the device has been installed, the output terminals must not be accessible.

    255.00 €
